Bitumen Packaging Solutions
Introduction to Bitumen Packaging
Importance of proper bitumen packaging
Key selection factors
Cost efficiency
Transportation and logistics
Storage requirements
Environmental considerations
Destination and export conditions
Main Types of Bitumen Packing
Steel Drum Packing
Industry-standard packaging
Safety and product integrity
Leak-proof transportation
Available drum types
150 kg
180 kg Standard Drum
200 kg Long Drum
| Specification | 150kg Drum | 180kg Drum | 200kg Drum |
|---|---|---|---|
| Material | Cold Rolled Steel | Cold Rolled Steel | Cold Rolled Steel |
| Height | 860 mm | 980 mm | 980 mm |
| Diameter | 500 mm | 500 mm | 500 mm |
| Body/Top/Base Thickness (mm) | 0.6 mm | 0.6 mm | 0.6 mm |
| Net Weight | 150 kg | 182 kg | 210 kg |
| Gross Weight | 158 kg | 192 kg | 220 kg |
| Empty Drum Weight | 8.5 kg | 9.5 kg | 10 kg |
| Leak Resistance | High | High | High |
Jumbo Bag Packing
Multi-layer flexible packaging
Bitu-bag / Polybag / Polycube systems
Reduced bitumen waste
Easy discharge process
Cost and environmental benefits
Available sizes
300 kg
1000 kg
1300 kg
Bulk Bitumen Shipment
Direct refinery-to-vessel transportation
Heated tanker and storage systems
Suitable for high-volume projects
Operational and logistics requirements
Bulk shipment process overview
Bitutainer
Insulated and heated tank containers
Higher carrying capacity than conventional tank containers
Direct delivery to project sites
Suitable for
Bitumen
PMB
Bitumen emulsions
Heavy fuel oil
Flexi-Tank Packaging
Flexi-Tank is an advanced bulk liquid transportation solution designed for shipping bitumen inside standard containers. Manufactured from durable multi-layer polypropylene and polyethylene materials, Flexi-Tanks are installed within insulated 20-foot containers and equipped with loading and discharge valves.
This packaging system is increasingly popular in international markets, particularly in Asia, due to its efficiency and cost advantages.
Key Features of Flexi-Tank
Installed inside standard 20ft containers
Multi-layer leak-resistant construction
Typically, 20 MT capacity
Insulated container walls
One or two loading/unloading valves
Reduced handling and logistics costs
Flexi-Tank Advantages
Cost-efficient containerized shipment
Faster loading and unloading
Reduced contamination risk
Suitable for long-distance transportation
Efficient use of container space
Oxidized Bitumen Packing
Dedicated solutions for solid and oxidized bitumen
Carton Packing
25 kg capacity
60×40×20 cm dimensions
Carton Pallet Shrink
Palletized and shrink-wrapped cartons
Standard 110×110 cm pallet
Polyamide Bags
25 kg capacity
Suitable for oxidized bitumen
Cold-water draining after filling
Polyester Lining
High thermal resistance
Protective inner layer for cartons
Bitumen Packaging Comparison
| Factor | Steel Drum | Steel Drum | Jumbo Bag | Flexi-Tank | Bulk |
|---|---|---|---|---|---|
| Transportation | Easy | Easy | Easy | Containerized | Specialized |
| Storage | Standard | Standard | Standard | Container-based | Heated |
| Packaging Cost | Medium | Low | Low | Low–Medium | Lowest |
| Bitumen Loss | 0–5% | 0–5% | 0–5% | Minimal | Possible transfer loss |
| Loading & Discharge | Easy | Easy | Easy | Valve System | Direct Pumping |
| Environmental Impact | Moderate | Low | Low | Moderate–Low | Higher Emissions |
Environmental Impact of Bitumen Packaging
Carbon emissions in bulk heating
Drum residue concerns
Jumbo bag recyclability
Efficient container utilization with Flexi-Tank
Sustainable logistics considerations
Choosing the Right Bitumen Packaging
Selecting the appropriate packaging depends on shipment size, destination, infrastructure, and budget.
